Digga PD6 Auger Drive

An innovative design allows the gearbox to go down the hole to maximise drilling depth without extentions, eliminating downtime and minimises maintenance, optimising your returns. Digga planetary auger drives are fitted with Digga/Danfoss bell motors specially designed for drilling and augering in most ground conditions.

Features

• Compact high torque Digga manufactured gearbox
• Highly efficient design with less moving parts
• Fitted with a DIGGA Bell Motor by Danfoss
• No case drain required
• Full range of shafts available upon request
• Extreme duty shaft locking system
• Drive fits down the hole for greater digging depth
• Low maintenance with 5yr gear box and 3yr motor warranty

Specifications:

• Recommended Flow - 70-115 lpm
• Max Torque - 5596 Nm
• Motor - 2K Geroler
• Pressure Valve Fitted - Optional
• Energy Control Valve - N / A
• Case Drain Required - No
• Max Pressure - Do not exceed 240 bar @ 60 lpm
• Max Flow - Do not exceed 115 lpm @ 130 bar
• Max Power - Do not exceed 25 Kw (34 hp)
• Overall Length - 730 mm
• Diameter - 240 mm
• Weight (no frame / hitch) - 89 Kg
• Std Output Shaft - 75 mm Square
• Swing Control - Optional
• Diggalign - Optional
• Halo - Optional
• Rec Auger - 4 Series, 6 Series
• Max Auger Dia Clay / Shale - 900 mm
• Max Auger Dia Earth - 1000 mm
